1. Weight capacity of 992lb
2. Loading diameter range from 1.96 - 48 inch
3. Roller assembly is mounted on screw adjusted stand for use as outboard support with positioner or headstock
4. Vertical adjustment of 205 mm to provides any height setting by turning the handles
Max. Loading weight 992lb
Wheel size (dia x. width) A 8 x 2.5 inch
Loading diameter range B - C 1.9 - 36 inch
Min. Stand height D -E 25.6 inch
Center distance F -G 8.5 - 17 inch
Frame width H 26 inch
Screw travel :8 inch
Packing size: 27 x 18.5 x 26 inch
N.W/G.W 121/ 145 lb
KAKA Industrial provides 12 months warranty for this product.
1.10 Day acceptance period from date of delivery. Damage claims and order discrepancies will not be accepted after this time.
2.You must obtain a Kaka Industral issued RGA number PRIOR to returning any materials.
3.Returned materials must be received at Kaka Industrial in new condition and in original packaging.
4.Altered items are not eligible for return.
5.Buyer is responsible for all shipping charges.
6.A 15% re-stocking fee applies to all returns.
