1. The Bead bending machine makes swaged plate, connection and so on of circular pipes, which refer to crushing the thin plates into the ribs in certain shapes.
2. The rigidity of the plates, pipes or metal components is strengthened.
3. Heavy and solid cast iron construction
4. Special steel adjustable bottom spindle
5. Complete with stand 4 sets standard rollers
6. Self-braking motor with subframe (E-type model ETB-12)
7. Easy to operate with foot pedal control (E-type model ETB-12)
Specification:
|
Item No.
|
173801
|
|
Model
|
TB-12
|
|
Thickness max
|
18Ga
|
|
Cylinder length
|
5-1/2”
|
|
Throat depth
|
8”
|
|
Motor power
|
0.75kW /1HP
|
|
Net weight(lbs)
|
106/120
|
|
Packing size (in)
|
26-1/2x12-3/4x23-3/4
|
Standard accessories:
4 sets of standard rollers
Optional accessories:
8 kinds of rollers
KAKA Industrial provides 12 months warranty for this product.
1.10 Day acceptance period from date of delivery. Damage claims and order discrepancies will not be accepted after this time.
2.You must obtain a Kaka Industral issued RGA number PRIOR to returning any materials.
3.Returned materials must be received at Kaka Industrial in new condition and in original packaging.
4.Altered items are not eligible for return.
5.Buyer is responsible for all shipping charges.
6.A 15% re-stocking fee applies to all returns.
